Surface Drilling Rig SWDH102S
  • Drilling diameter: 76-127mm
  • Max. hole depth: 24m
  • Max. feed force: 25kN
Advantages of Surface Drilling Rig
  • Strong climbing ability
  • Great flexibility and performance
  • Compact structure
  • Ideally suitable for difficult terrains
  • Low energy consumption
  • High drilling speed
Features

High power hydraulic rock drilling machine features high impact power and reverse percussion function, efficiently reducing the risk of jamming while making the rock drilling machine more endurable;

All key parts of the drill rig are purchased from world's well-known brands to ensure reliable operation, high working efficiency and low energy consumption;

The engine and compressor are perfectly integrated in this surface drilling rig, and both power and economy modes are available to match your task of rock drilling, giving high adaptability and saving more energy;

The compact structure design allows for fast tramming and exceptional rough terrain capabilities;

A sturdy folding boom with good coverage can drill holes with multiple angles, and hole positioning can be conducted in a fast manner;

Technical Parameters
Operation parameters
Hole diameter mm 76-127
Drill steel dimensions T45, T51
Drill pipe length mm 3660
Hole depth m 24
Hydraulic rock drill rig
Impact power kW 18
Rotation torque Nm 1000
Rotation speed Nm 0-150
Engine
Model CAT C7.1
Power kW/rpm 168/2200
Fuel tank capacity L 450
Air compressor
Working pressure bar 10
Displacement m³/min 10
Boom
Type Folding boom
Lifting angle ° 70 to -10
Folding angle ° 65 to165
Swing angle ° 20 to -30
Feed
Total feed length mm 7300
Feed extension travel mm 1200
Forward inclination ° 140
Rollback ° -20 to 90
Max. feed rate m/s 0.8
Max. feed force kN 25
Undercarriage
Max. tramming speed km/h 4.2
Max. traction force kN 100
Gradeability ° 25°
Swing angle of crawler frame ° -7 to 12
Ground clearance of undercarriage mm 400
Overall dimensions
Weight kg 15000
L×W×H (working) m 9.2×2.6×8.6
L×W×H (transportation) m 1.2×2.6×3.5

Statement of technical specification: all parameters above are subject to change due to the continuous improvement of the product, please contact us to get the latest info updates.


Surface drilling rigs are hydraulic drill rigs typically designed for small to medium-scale quarries and small-sized open pit mines, suitable for rock drilling applications where rock hardness exceeds F10 in aggregate quarrying, civil engineering, road construction, open pit mining, hydropower plant construction and other blasthole drilling projects. This hydraulic drilling rig is becoming more prevalent in open pit mining thanks to its high efficiency embodied in high drilling speed and extremely low loss of efficiency, as well as more energy efficient in contrast to pneumatic drilling rig.
