BM-113 Overhead condenser microphone

BM-113 Overhead condenser microphone
BM-113 Overhead condenser microphone
BM-113 Overhead condenser microphone
Request a Quote
Key Features:

Anti-Interference

  • Excellent RF shielding effect, effectively avoiding RF interference.
  • BM-113 Cardioid polar pattern.

Clear Sound Quality

  • High-quality speech reproduction.
  • High gain-before-feedback.
  • Flat and wide frequency response.

Convenient Installation

  • Fixing or suspended hanging installation.
  • Standard installation or embedded installation.

Hidden design

  • BM-113 flexible gooseneck for optimal positioning.
BM-113 Overhead Microphones

This frequency response curve and polar pattern corresponds to a typical production sample for this microphone.(frequency response measurement error: ±2.5dB)

BM-113 Frequency Response 0dB=18 mV/Pa
BM-113 Polar Pattern
Technical Parameters:
  • Capsule Type: Condenser cardioid polar pattern
  • High Pass filter: 100Hz, 18dB/octave
  • Frequency Response: 35Hz-18 kHz
  • Sensitivity: -32dB, 1V@1Pa
  • Output Impedance: 200Ω
  • Max. Input Sound Level: 130dB, 1KHz@1%T.H.D.
  • Dynamic Range (typical): 110dB, 1 kHz at highest sound level
  • S/N: >68dB,1KHz@1Pa
  • Phantom Supply: DC12-52V
  • Current Consumption: 8mA (BM-112 Typical)
  • Output Connector: 3P fast connector
  • Dimension (mm): 90(L) ×86(W) ×153(H)
  • Weight: 95g
  • Color: White
