PM-100 Condenser microphones

PM-100 Condenser microphones
PM-100 Condenser microphones
PM-100 Condenser microphones
Request a Quote
Key Features:
  • Human sound tailored and works in conjunction with electroacoustic technology for the best voice reproduction. It is suitable for professional small or medium scale performances and studios.
  • The cardioid polar pattern reduces sound pickup from sides and rear.
  • Rugged, all-metal designed with noise isolation and long service life.
  • High-strength, antiskid, metal mesh enclosure provides extra protection.
  • Built-in high-pass filter circuit to reduce breathes pickups, as well as surrounding noises (such as car engines, air conditioner noises, echoes, mechanical vibration noises and more)
  • The PM-100 is used for professional voice recording, and is powered using an 11 to 52V phantom power supply, or using the built in phantom power supply in the mixing console, or using an individual Relacart P-48V1S single channel phantom power supply.
  • The 3-pin XLRM connector on the microphone is a low resistant balanced output, the voice signal is transmitted using #2 and #3 pin, the #1 pin is the ground wire.
  • The cables must be connected correctly with corresponding pins, 1-1, 2-2 and 3-3 to ensure the voice fidelity.
  • No high-temperature exposure, keep the microphone in an environment with temperatures lower than 43°C and low humidity.
Technical Parameters:
Capsule: Condenser
Polar Pattern: Cardioid unidirectional
Frequency Response: 50Hz-20khz
Sensitivity: -44dB, 1V at 1Pa
Output Impedance 280 Ω
Max. Sound Input: 120dB,1kHz at 1%T.H.D.
Dynamic Range: 115dB, 1kHz at max. SPL
S/N: >72dB(A),1kHz at 1Pa
Phantom Power Supply: 11-52VDC
Current Consumption: 4mA (Typical)
Output Connector: Built-in 3-pin XLRM male plug
Dimension (mm): φ51x190
Weight (g): Approximately 365 g
  • Capsule: The key component to transform voice into signal.
  • Connector: Connect to receiver.
