High Speed Special Cord Braiding Machines

High Speed Special Cord Braiding Machines
High Speed Special Cord Braiding Machines
High Speed Special Cord Braiding Machines
Request a Quote

High speed special cord braiding machines are applied for weaving different special cords, like border embroidered, double surface, triangle, and square lace. The machine features simple operation and produces high quality products with minimal loss and manpower.

Parameters
Model Application Carriers per head Ribbon number Horngear size Motor power Voltage Rpm. hornger Carrier type
COTR3-4A Three strands twisted rope 3 4 / 3/4HP(0.55KW) 220V-380V / A
COTR3-4B Three strands twisted rope 3 4 / 3/4HP(0.55KW) 220V-380V / B
COTR3-4A-W Three strands twisted rope 3 4 / 3/4HP(0.55KW) 220V-380V / A
COTR3-4B-W Three strands twisted rope 3 4 / 3/4HP(0.55KW) 220V-380V / B
COBS34-2AB-E Border embroidered 34 2 90 1HP(0.75KW) 380v 360 AB
COBS26-2AB-S Double surface 26 2 90 3/4HP(0.55KW) 220V-380V 360 AB
COBS34-2AB-S Double surface 34 2 90 1HP(0.75KW) 380v 360 AB
COBS27-2AB-T Ttriangle cord 27 2 90 3/4HP(0.55KW) 220V-380V 360 AB
COBS36-2AB-S Suare cord 36 2 90 1HP(0.75KW) 380v 360 AB
COBS46-2AB-P Person type 46 2 90 1.5HP(1.1KW) 380v 360 AB
COBS36-2AB-T Tthree colors cord 36 2 100 1HP(0.75KW) 380v 360 AB
COBS39-1AB-T Three color cord 39 1 100 1HP(0.75KW) 220V-380V 340 AB
COBS8-4A-R Ruyi cord 8 4 112.5 3/4HP(0.55KW) 220V-380V 315 A
COBS52-2AB-S Four color cord 52 2 90 1HP(0.75KW) 380v 360 AB
COBJ12-2A Jack stay cord 12 2 / 3/4HP(0.55KW) 220V-380V 900 A
COB18-2A Jack stay cord 18 2 / 3/4HP(0.55KW) 220V-380V 900 A
COBJ20-2A Jack stay cord 20 2 / 1HP(0.75KW) 220V-380V 900 A
COBJ12-2B Jack stay cord 12 2 / 1HP(0.75KW) 220V-380V 900 B
COB18-2B Jack stay cord 18 2 / 1HP(0.75KW) 220V-380V 900 B
COBJ20-2B Jack stay cord 20 2 / 1.5HP(1.1KW) 380v 900 B
COBF39-1A Three color cord 39 1 / 0.75KW 220V/380V 340 A
COBF52-2AB-S Four color cord 52 2 / 0.75KW 380V 360 AB
COBR46-2AB Bias tape/thick-thin tape 46 2 / 1.1KW 380V 340 AB
