Air-Cooled Silent Gasoline Generators (Single Cylinder)
Request a Quote
5kW/8kW/9kW Gasoline Genset
5kW/8kW/9kW Gasoline Genset
Features
- The air-cooled, silent gasoline generator is powered by a single-cylinder, 4-stroke, air-cooled engine with low emissions and stable output—ideal for residential backup, outdoor activity, or mobile operations.
- Built with a full copper alternator and automatic voltage regulator (AVR), ensuring consistent voltage and strong excitation performance for sensitive loads.
- Reinforced with a heavy-duty steel frame, the gasoline genset comes standard with caster wheels, allowing smooth transport and deployment in varied environments.
- This silent gasoline generator offers multiple safety features, including a low oil alert and an overload circuit breaker to protect the engine and electrical system during operation.
- The air-cooled genset is equipped with a customized muffler system for quiet operation and enclosed design to reduce noise output, which is ideal for use in quiet neighborhoods or sound-sensitive settings.
Specifications
| Genset Model | | | | |
| Alternator | Excitation Mode | AVR (automatic voltage regulation) | ||
| Rated Output Power (kW) | 5.0 | 8.0 | 9.0 | |
| Max. Output Power (kW) | 5.5 | 8.5 | 9.5 | |
| Rated Voltage (V) | 230V | 230V | 230V | |
| Rated Current (A) | 21.7A | 34.8A | 39.0A | |
| Max. Current (A) | 23.9A | 37.0A | 41.0A | |
| Rated Frequency | 50HZ | 50HZ | 50HZ | |
| Phase | Single phase | Single phase | Single phase | |
| Power Factor (COSφ) | 1.0 | 1.0 | 1.0 | |
| Insulation Class | F | F | F | |
| Engine | Engine Model | DH190 | DH500 | DH550 |
| Bore Size×Stroke (mm) | 90×66 | 94×76 | 94×76 | |
| Displacement (cc) | 420 | 500 | 550 | |
| Fuel Consumption (g/kWh) | ≤374 | ≤374 | ≤374 | |
| Ignition | Electronic ignition | |||
| Engine Type | 1 cylinder, 4-stroke, air-cooled | |||
| Fuel Type | 90# lead-free gasoline | |||
| Oil Capacity (L) | 1.1 | 1.1 | 1.1 | |
| Starting System | Electric Start | |||
| Others | Fuel Tank (L) | 25L | 25L | 25L |
| Battery | 12V-14AH maintenance-free battery | |||
| Noise Level (dBA/7m) | 75 | |||
| Dimension (mm) | 875×560×785 (without handle) | |||
| Weight (kg) | 145kg | 156kg | 165kg | |
