12mm Flat Insulated Shaft Rotary Encoder, EC12-1 Series

12mm Flat Insulated Shaft Rotary Encoder, EC12-1 Series
12mm Flat Insulated Shaft Rotary Encoder, EC12-1 Series
Request a Quote

Part Number

EC12-1
Dimensions

The EC12-1 encoder has a compact structure, an excellent sealing performance, and a push switch operation. It is ideal for use in automobile audio, other audio devices, home appliances, and more.

Parameters
Diameters 12mm
Shaft plastic flat shaft
push-on switch without
Rotational torque 80~200gf.cm
Number of detents 16/20/32
Push-pull strength ≥8kgf
Linear Accuracy ±1%
Number of pulses 24Pulses/360°
Rated power DC5V
Voltage proof 1 min at AC50V
Operating life ≥30000cycles
Dimensions
