YEHL2 Electro-Hydraulic Lift Valve
Request a Quote
Hydraulic control valve for precise control of tractor attachment lifting and lowering
The electro-hydraulic lift valve uses electro-proportional signals to precisely control spool opening, adjusting output flow at the working port with a capacity of up to 120 L/min. This enables accurate lifting and lowering of tractor attachments to meet various operational requirements in different industrial applications such as modern farming.
Features
- Modular, compact design that can be combined with multi-spool valves for integrated hydraulic control
- Low pressure loss and high efficiency, reducing overall machine energy consumption
- Electro-proportional flow control with high sensitivity, ensuring smooth, precise implement adjustments
Specifications
| Max. Operating Pressure | 250bar |
| Rated Flow | 120L/min |
| Fluid Temperature Range | -40℃～100℃ |
| Ambient Temperature Range | -40℃～80℃ |
| Surface Treatment | Nickel plated |
| Oil Viscosity Range | ISO 20～400mm²/s |
Applications
Ideal for tractor depth control systems, the hydraulic lift valve enables proportional and precise lifting and lowering of attachments, maintaining consistent tillage depth for improved farming accuracy and productivity.
