Overall specification Overall length (mm) 10400 Engine Engine model YC6J230-20
Overall width (mm) 2480 Manufacturer Chinese Yuchai
Overall height (mm) 3400 Engine position Front
Body inside height (mm) 1945 Engine Type 6 cylinders in line, turbocharged, water cooling, inter-cooling
Wheel base (mm) 5000 Max power(kw/rpm) 170
Front/rear overhang (mm) 2200/3200 Max torque(N.m/rpm) 810
Approach/departure (º) 11/9 displacement(L) 6.5
First step height (mm) 420 Bore/stroke mm 105X125
Max G.V.W.kg 13500 fuel Diesel
Seats capacity (person) 44 1 Emission standard Euro II
Max. speed km/h 100 Steering wheel position LHD
Luggage capacity (m3) 6.3
Items Standard Equipments
Chassis Data Manufacturer Made in China
Chassis model Made in China
Gear box Manual 6 speed S6-80
Front axle front axle,5.5 Ton
Rear axle rear axle, 9Ton
Suspension leaf spring 10/12
Steering Integral power steering
Brake Dual circuit air braking, drum brake
Fuel tank 380 L
Tyre 11R22.5 Double Coin
Battery /dynamo 6-QA-165/110A
Others Air dryer, clutch booster, brake exhaust, ABS
Bus specification Body construction Semi-integral,
Interior trim Formed soft interior trim, air distributors and reading lights in the luggage rack
Door & door pump Front aluminum door, outside swing, domestic door pump
Window, windscreen Front rubber-laminated windscreen,
rear window toughened safety glass
sliding side window
Rear mirror system Manual motion
A/C system 26000Kcal/h Driving fan
Heating system Front windscreen defroster
Video system 250G MP5 one 17''LCD in front
Lamps New type combination lamp front and rear, rear brake light
Wiper Electric wiper
Luggage door Steel panel overturning opening door
Seat 2 2 layout, ZTZY3192,adjusting type,
Paint High quality paint
others skid proof floor leather, electric clock, windscreen sun visor, side window curtain, fire extinguisher, Stainless steel decoration cover, bull bar
