Wheeled Excavator, FK220-9L

Wheeled Excavator, FK220-9L
Wheeled Excavator, FK220-9L
Wheeled Excavator, FK220-9L
Wheeled Excavator, FK220-9L
Request a Quote
Basic Information
    1. Total weight
      21750kg
    1. Standard bucket capacity
      1.0m³
    1. Rated power
      124/2050kW/rpm
Performance Parameters
Engine Cummins
Engine rated power 124/2050kW/rpm
Gradeability 70 % (35°)
Digging force (stick) 100.3kN
Digging force (bucket) 132.3kN
Travel speed 30km/h
Platform rotation speed 12.5r/min
Job Parameters
Max. digging height 9725mm A
Max. digging depth 6405mm B
Max. digging radius 9911mm C
Max. digging radius on ground 9685mm D
Max. vertical digging depth 4177mm E
Max. dumping height 6882mm F
Min. turning radius 3622mm G
Shipping Dimensions
Overall length (transport state) 9455mm
Overall width (transport state) 2530mm
Overall height (transport state) 2490mm
Other Parameters
Wheelbase 2600mm E
Track width 1944mm F
Counterweight ground clearance 1223mm G
Min. ground clearance 350mm H
Tail length 2353mm I
Tail swing radius 2450mm I’
Upper platform width 2470mm J
Fuel tank capacity 295L
Hydraulic oil tank capacity 165L
