50-55HP Wheeled Tractor

Request a Quote

View All: http://ytocorp.com/1-1-5-55hp-wheeled-tractor.html

Produced with advantage technology, the 50-55HP wheeled tractor has passed E-Mark certification. As a professional Chinese wheeled tractor supplier, our company has the self-owned brand for the 4 cylinder diesel engine, which features large torque reserve factor, strong power, and high economic efficiency.

Features

The heavy duty tractor is manufactured with reliable and durable transmission. So, it is quite suitable for the operation with heavy load. Moreover, the shuttle shift structure of the transmission system makes for high working efficiency.
There is integrated axle housing provided for the front drive axle for big load bearing capacity. The outstanding sealing property effectively prevents the drive axle from being damaged.
Our 50-55HP wheeled tractor can be equipped with clutch pedal for safe startup. So, accident caused by incorrect startup can be avoided.

Specifications

Model	YTO-MF504		YTO-MF554	YTO-MF500	YTO-MF550
Tractor
Type		4×4		4×2
Overall Dimensions (L×W×H)(mm)		3910×1745×2545	3910×1745×2565	3910×1745×2545	3910×1745×2565
Wheel Base (mm)		2063	2127	2063	2127
Min. Ground Clearance(mm)		350		400
Min. Operating Mass (kg)(ROPS)		2326	2380	2130	2180
Tyre Size (F/R)		8.3-20/12.4-28	8.3-20/13.6-28	6.00-16/12.4-28	6.50-16/13.6-28
Wheel Track (F/R )(mm)		1250/1400-1600		1350-1550/1400-1600
Gear Shift (F/R)		8/8
Speed Range(km/h)(F/R)		2.37-31.06/2.03-26.62	2.47-32.38/2.12-27.75	2.37-31.06/2.03-26.62	2.47-32.38/2.12-27.75
Lifting Force (610mm)(KN)		≥8.28	≥9.09	≥8.28	≥9.09
Lifting Force (Link Joint)(KN)		10.66	11.70	10.66	11.70
Diesel Engine
Model	YT4A2-22		YT4A2-22	YT4A2-22	YT4A2-22
Type	4-cylinder, in-line, vertical, water cooled, 4 stroke
Displacement (L)	4.15		4.15	4.15	4.15
Rated Power/Rotating Speed (kW/rpm)	36.8/2200		40.4/2200	36.8/2200	40.4/2200
