Stone Impact Crusher Plant
Request a Quote
The track-mounted crawler mobile impact crusher is designed with a heavy-duty super rotor, large crushing cavity, thick impact aprons, alloy high wear-resistant blow bars, and a hydraulic opening mechanism. These unique features provide greater crushing capacity and crushing ratio, stable quality, low production costs, and easy operation and maintenance. It is suitable for crushing soft to medium-hard ores and rocks. The crushed products have a cubic shape, a low content of flaky particles, and are free of micro-cracks.
- High-Performance Crushing: Featuring a high-inertia rotor and an extra-large crushing chamber to maximize throughput capacity and reduction ratios.
- Superior Mobility: Designed for rapid, hassle-free relocation between job sites.
Applicable Materials
- Metal Ores
- Non-Metal Ores
Technical Specifications
| Model | |||||
| Overall stone crusher plant | Capacity (t/h) | 130-200 | 180-280 | 220-350 | 220-350 |
| Power(kW) | 240 | 270 | 332.7 | 343.7 | |
| Feeder | Model | GZD1040 | GZD1040 | GZD1245 | GZD1245 |
| Power(kW) | 5×2 | 5×2 | 5×2 | 5×2 | |
| Impact crusher | Model | PFG1214 | PFG1313 | PFG1315 | PFG1315 |
| Power(kW) | 160 | 200 | 250 | 250 | |
| Vibrating screen | Model | 2YKJ1340 | 2YKJ1845 | 3YKJ2250 | 3YKJ2250 |
| Power(kW) | 7.5×2 | 9×2 | 11×2 | 11×2 | |
| Mud conveyor | Size (length×belt width) | 6m×B500mm | 6m×B650mm | 6m×B650mm | 6m×B650mm |
| Power(kW) | 3 | 5.5 | 5.5 | 5.5 | |
| Main conveyor | Size (length×belt width) | 10.5m×B1200mm | 11m×B1200mm | 12m×B1200mm | 12m×B1200mm |
| Power(kW) | 11 | 15 | 15 | 15 | |
| Underscreen conveyor | Size (length×belt width) | 7m×B1000mm | 8m×B1200mm | 8m×B1200mm | 8m×B1200mm |
| Power(kW) | 11 | 11 | 11 | 11 | |
| Iron removal conveyor | Size (length×belt width) | 3m×B800mm | 3m×B800mm | 3m×B800mm | 3m×B800mm |
| Power(kW) | 3.2 | 3.2 | 3.2 | 3.2 | |
| Side conveyor 1 | Size (length×belt width) | 9m×B500mm | 9m×B650mm | / | 9m×B650mm |
| Power(kW) | 5.5 | 5.5 | / | 5.5 | |
| Side conveyor 2 | Size (length×belt width) | / | / | / | 9000×B650 |
| Power(kW) | / | / | / | 5.5 | |
| Return transfer conveyor | Size (length×belt width) | 3m×B500mm | 4m×B650mm | 4m×B650mm | 4m×B650mm |
| Power(kW) | 3 | 3 | 5.5 | 5.5 | |
| Return conveyor | Size (length×belt width) | 11m×B500mm | 11m×B500mm | 11m×B650mm | 11m×B650mm |
| Power(kW) | 11 | 11 | 11 | 11 | |
Projects
Mobile Crushing Plant Retrofit & Upgrade Project in Foshan, GuangdongMobile Crushing Plant Project of China Communications Construction Company (Qingyuan)300TPH Mobile Crushing Plant Project in Jiangyin, Jiangsu
How do mining contractors decide between wheel-mounted and track-mounted mobile plants?
The choice depends primarily on mobility requirements. Wheel-mounted plants offer superior road transportability. Track-mounted plants are engineered for rugged terrain and short-distance frequent movements.
How do quarry owners evaluate the reliability in turnkey crushing solutions?
Reliability is assessed through four aspects: component wear resistance, system integration, the level of automation, and the strength of the after-sales service infrastructure, including the availability of spare parts.
Infrastructure projects require on-site crushing of road base material and dam aggregates, with quick supply of qualified material. How does the track-mounted impact crusher accelerate project progress?
The track-mounted impact crusher adopts an integrated structure and full-track hydraulic drive design, enabling flexible movement and quick positioning at narrow or rugged construction sites. With its high crushing ratio three-cavity impact chamber structure and large-capacity feeding system, it efficiently crushes and screens road base material and dam aggregates on-site, significantly shortening material transport and construction cycles, thus supporting project progress efficiently.
