Stone Jaw Crusher Plant
The track-mounted mobile jaw crusher plant is equipped with a European-style jaw crusher. This is a newly designed crusher optimized in terms of structure, material and craftsmanship. It features a unique structure, reliable operation, simple operation, high crushing ratio, and high output, making it the preferred equipment for crushing various hard and highly abrasive rocks and minerals. It is mainly used for hard rock crushing, aggregate production, in-pit crushing, as well as mining, waste recycling, cement production, and tunnel crushing.
- Dual-Power Versatility: Diesel & electric hybrid drive for maximum fuel efficiency and operational flexibility.
- Superior Mobility: Designed for rapid, hassle-free relocation between job sites.
- High Reduction Ratio: Optimized crushing chamber for maximum efficiency and high-quality output.
- Metal Ores
- Non-Metal Ores
| Model | ||||
| Feeder | Loading height (mm) | 4200 | 4200 | 4500 |
| Stockpile volume (m³) | 4 | 5 | 6 | |
| Jaw crusher | Max. feeding size (mm) | 400 | 650 | 750 |
| Max. output size (mm) | 180 | 240 | 270 | |
| Main belt conveyor | Discharge height (mm) | 3200 | 3600 | 3800 |
| Size (length×belt width) | 10m×B1000mm | 13m×B1000mm | 14m×B1000mm | |
| Side belt conveyor | Stockpile height (mm) | 1750 | 1750 | 1750 |
| Size (length×belt width) | 4.3m×B650mm | 4.3m×B650mm | 4.3m×B650mm | |
| Overall stone crusher plant | Crushing capacity (t/h) | 65-275 | 110-400 | 190-625 |
| Total power (kW) | 117 | 137 | 167 | |
Track-mounted jaw crushers are the preferred choice for remote quarries where infrastructure, such as paved roads and stable power grids, is limited. Their self-propelled mobility allows for easy transport across rugged landscapes.
For metal ore processing, jaw crushers or gyratory crushers are typically deployed for the primary crushing stage. This is usually followed by secondary and tertiary crushing, often using cone crushers, within a closed-circuit screening system. This configuration ensures an optimized and consistent feed size for the downstream grinding mills.
