Stone Cone Crusher Plant
Request a Quote
The track-mounted mobile cone crusher integrates the latest research results in crushing technology, hydraulic technology, automated control systems, and manufacturing. It can be equipped with various cavity configurations according to customer requirements for material processing, ensuring high output, excellent product shape, and reduced wear-and-tear costs for any application.
- Dual-Power Versatility: Diesel & electric hybrid drive for maximum fuel efficiency and operational flexibility.
- Superior Mobility: Designed for rapid, hassle-free relocation between job sites.
- High Reduction Ratio: Optimized crushing chamber for maximum efficiency and high-quality output.
Applicable Materials
- Metal Ores
- Non-Metal Ores
Technical Specifications
| Model | ||||
| Feeder | Loading height (mm) | 2300 | 2400 | 2500 |
| Size (length×belt width) | 6m×B650mm | 6m×B1000mm | 6m×B1000mm | |
| Main belt conveyor | Delivery height (mm) | 4100 | 4100 | 4100 |
| Size (length×belt width) | 8.5m×B650mm | 10m×B1000mm | 11.5m×B1200mm | |
| Output belt conveyor | Discharge height (mm) | 3150 | 3150 | 3150 |
| Size (length×belt width) | 6.5m×B1000mm | 7.5m×B1200mm | 7.5m×B1400mm | |
| Side conveyor | Size (length×belt width) | 2.5m×B650mm | 2.5m×B650mm | 2.5m×B650mm |
| Return conveyor | Size (length×belt width) | 8.5m×B500mm | 10m×B500mm | 11m×B500mm |
| Return screen | Model | 2YKJ1545 | 2YKJ1850 | 2YKJ2050 |
| Overall stone crusher plant | Crushing capacity (t/h) | 90-250 | 110-440 | 135-630 |
| Total power (kW) | 225 | 300 | 396 | |
Projects
300 TPH Mobile Crushing Plant Project in Zhaoqing, GuangdongMobile Crushing Plant Project in GuangxiMobile Crushing Plant Project in GansuMobile Crushing Plant Project in FujianMobile Crushing Plant Project in Qingyuan, Guangdong
Why do startup mining operators choose mobile crushing plants for rapid production?
Mobile stations require minimal civil engineering and offer fast production startup, making them ideal for quickly achieving output in the early stages.
What are the key expectations behind a "turnkey" quarry plant design request?
The typical intent is to have a single-source provider complete the entire lifecycle from design, equipment provision to delivery and commissioning, reducing coordination risks among multiple parties.
Construction waste contains complex materials like rebar and concrete. How does the track-mounted cone crusher prevent damage and ensure high-quality recycled aggregates?
The track-mounted cone crusher is equipped with a high-performance symons cone crusher, utilizing the principle of laminated crushing and adjustable hydraulic discharge opening control technology. This ensures a high fine crushing ratio while maintaining uniform particle shape, low content of flaky particles, and stable crushing force output through an intelligent constant power control system, ensuring sustained high-efficiency production.
