Jacquard Blanket & Plush Fabric Warp Knitting Machine
Request a Quote
GE2886 Raschel Machine
Double needle bar raschel knitting machine for producing plush fabrics and blankets with jacquard patterns
Applications
Eco-friendly air conditioning filter materials, short, medium, and long plush fabrics and blankets with jacquard patterns.
Features
- Jacquard blanket & plush fabric warp knitting machine uses an oil immersed cam-linkage mechanism and fixed ground bars.
- Raschel warp knitting machine has functions of electronic yarn let-off and EL pattern drive with electronic guide bar drives.
- Finished plush products are not prone to shedding.
Specifications
- Needle type Individual latch needle, block latch needle
- Gauge E16, E18, E22
- Number of bars 5/6 bars
- Distance between knocking-over bar 9-50mm
- Working width 100"/110"/138"
- Max. speed 700 rpm
| Machine Model | Dimensions (L×W×H) | Floor Area (m²) | Machine Weight (kg) | Total Power (kW) |
| 4400×5600×3690 | 24.64 | 8500 | 16 | |
| 4350×6050×3750 | 26.3 | 10000 | 16 | |
| 5100×6050×3750 | 30.8 | 12000 | 17.75 |
