GE385 Raschel Machine

Double needle bar raschel knitting machine for producing plush fabrics used in plush toys, apparel, blankets and home upholstery

Applications

Plush fabrics used in plush toys, apparel, blankets and home upholstery

Features
  • High speed plush fabric warp knitting machine uses an oil immersed cam-linkage mechanism and fixed ground bars.
  • Raschel warp knitting machine utilizes ear-lowering pieces and wire guards to prevent breakage during fabric insertion.
  • The yarn let-off device controls the 2 rollers for positive yarn feeding.
  • The plush has a pile height of 3.5-25mm.
Specifications
  • Needle type Individual latch needle, block latch needle
  • Gauge E18, E22
  • Number of bars 5 bars
  • Working width 90"/100"/110"/138"/150"/158"/170"/184"/210"
  • Max. speed 950 rpm
Machine Model Dimensions (L×W×H) Floor Area (m²) Machine Weight (kg) Total Power (kW)
GE385-90" 3700×6050×3750 22.6 8000 13.5
GE385-100" 4000×6050×3750 24.5 9250 13.5
GE385-110" 4350×6050×3750 26.4 10000 13.5
GE385-138" 5100×6050×3750 30.3 12000 15.75
GE385-150" 5100×6050×3750 30.3 12000 15.75
GE385-158" 5300×6050×3750 32.1 12500 17.5
GE385-170" 6100×6050×3750 36.9 14500 17.5
GE385-184" 6550×6050×3750 39.6 15250 18.5
GE385-210" 7250×6050×3750 43.9 16500 24.7
