PET Monofilament Self Closing Sleeving

PET Monofilament Self Closing Sleeving
PET Monofilament Self Closing Sleeving
PET Monofilament Self Closing Sleeving
PET Monofilament Self Closing Sleeving
Request a Quote

Material: PET Monofilament
Working temperature: -40℃-150℃
Melting temperature: 240℃
Edge overlap: ≥75%
Product certification: SGS, UL, DIN5510
Optional filament diameter: 0.25

The PET monofilament self closing sleeving features flame retardant rate of V0, and then naturally wrapped using special technology. The degree of wrapped coverage reaches 75%. This product features an excellent heat dispersion, fire resistance, wear resistance and beautiful appearance. It is convenient for braiding sleeving, and the open structure is beneficial for reassembly, recondition and maintenance of wires.

Application
The PET monofilament self-closing sleeving is usually used in wiring in high speed train system.

Parameters
Size and specification INQUIRY
Model Inner diameter(d) Edge overlap(%) Coverage diameter Package(L)
MX-PJ006 6mm 75% 6mm 25m/reel
MX-PJ008 8mm 8mm 25m/reel
MX-PJ010 10mm 10mm 25m/reel
MX-PJ013 13mm 13mm 25m/reel
MX-PJ016 16mm 16mm 25m/reel
MX-PJ019 19mm 19mm 25m/reel
MX-PJ025 25mm 25mm 25m/reel
MX-PJ032 32mm 32mm 25m/reel
MX-PJ038 38mm 38mm 25m/reel
MX-PJ045 45mm 45mm 25m/reel
MX-PJ050 50mm 50mm 25m/reel
