Hydraulic Vane Pump, V Series

Request a Quote

View All: http://hydraulicpump-motor.com/1-4-4-v-series-pumps.html

The V series hydraulic vane pump is a high-performance composition vane pump developed for industrial hydraulic system applications like plastic injection machinery, rubber machinery, die-casting machinery, and machine tools.

The composition vanes with the design to reduce the impact of the vane on the stator, maintaining stable performance and long service life under higher working pressure and high speed.
The structure of 12 composition vanes can reduce flow pulsation to a minimum level and is proven to be low noise.
Multiple displacement version available. The cartridge structure of the pump core gives the user smooth operation and convenient maintenance.

Technical Parameters

Models	Displacement code	Geometric displacement (mL/r)	Anti-wear hydraulic fluid or phospholipid		Water glycol fluid		Water-in-oil emulsion		Min. speed (r/min)
			Max. pressure (MPa)	Max. speed (r/min)	Max. pressure (MPa)	Max. speed (r/min)	Max. pressure (MPa)	Max. speed (r/min)
20V	2	7.5	13.8	1800	13.8	1500	6.9	1200	600
	3	10
	4	13
	5	17	20.7		15.9
	6	19
	7	23
	8	27
	9	30
	10	32.5
	11	36
	12	40	15.9
	14	45	13.8		13.8
25V	10	32.5	17.2	1800	15.9	1500	6.9	1200	600
	12	40
	14	43
	15	45
	17	55
	19	59
	21	67
35V	21	67.0	17.2	1800	15.9	1500	6.9	1200	600
	25	81
	30	97
	32	100
	35	112
	38	121
	45	142
45V	42	138	17.2	1800	17.2	1500	6.9	1200	600
	45	142
	50	162
	57	183
	60	193
	66	212
	75	237	13.8		13.8
