SHO-CMX01 Medical Imaging

Digital radiography system with motorized automatic positioning

The ceiling-mounted digital X-ray machine gives you versatile and high-quality imaging for head, chest, abdomen, lumbar spine, and limb examinations. Designed for hospitals of all sizes, it supports PA, LAT, and clinical static imaging, ensuring accurate diagnostics in a wide range of applications.

With its compact design and flexible movement, this system combines a floor-mounted table with a wall-mounted stand, making it easy for you to position patients efficiently while expanding your imaging capabilities. The motorized height-adjustable radiographic table enhances workflow, allowing for faster and more precise examinations.

This radiographic equipment is equipped with an 80kW, 1000mA high-voltage generator, a Siemens X-ray tube, Vieworks wireless flat panel detector, motorized collimator, and a 23.8-inch Dell workstation display. A 10-inch LCD touchscreen control panel simplifies operation, so you can focus on delivering the best care to your patients.

Specifications
Model SHO-CMX01 Series
Output power 80 kW
Current 10-1000 mA
Voltage 40-150 kv
Exposure time 0.001-10 s
Focus size 0.6/1.2 mm
Flat Panel Detector (Wireless)
Type Amorphous Silicon
Scintillator Cesium Iodide
Active Area 17×17 inch (43×43 cm)
Active Pixel 3072×3072
Pixel Pitch 140 um
A/D Conversion 16 bits
DQE ≧70%
Spatial Resolution 37 lp/cm
Acquisition time ≤2S
Collimator
Operating mode Electric
Max. Field of view 45×45 cm
Illuminant LED
Bucky stand
Vertical travel 1.4 m
Phototharapy Table
Tabletop transverse travel 260 mm
Tabletop longitudinal travel 750 mm
Tabletop vertical travel 210 mm
Workstation
Monitor 23.8’’ LCD Dell brand
CPU ≥ 3.7GHz
Memory ≥ 4 GB
HDD ≥ 1T
DICOM3.0 Query for integration with any PACS
X-Ray Imaging
Head radiograph
Limb radiograph
Abdominal radiograph
Lumbar radiograph
Chest radiograph

Looking for a ceiling-mounted X-ray system that enhances efficiency and accuracy? Contact us today to find the right solution for your facility!
