6127H Coach (Compass)

Request a Quote

View All: http://zhongtongbuses.com/1-5-3-6127h-coach/index.html

This bus is specially designed for Africa market with Cummins engine in front. It features excellent cooling system, strong power, and low fuel consumption. The electric retarder works to enhance braking capacity, shorten braking distance and make the vehicle much safer. The metal covering in the front wall enhances the coach's safety. The coach possesses a powerful passing ability with the approaching angle reaching 13°.

Bus parameters	total length (mm)	12590	Engine	model	ISLe 375 40
	total width (mm)	2550		manufacturer	Cummins
	total height (mm)	3830		position/fuel	real
	inner height (mm)	2020		type	straight 6 cylinder, medium cooling
	wheelbase	6400		max power (kw)	275
	front/rear suspension (mm)	2800/3390		max torque (N.M)	1550
	approach angle/departure angle (º)	8/7.5		displacement (ml)	8900
	height of single step (mm)	≤380		cylinder diameter × stroke (mm)	126X130
	max total mass defined by factory (kg)	13370/18000		fuel	diesel
	rated capacity (person)	51 1 1		emission standard	European standard 4
	max speed (km/h)	120	Certification		ISLe375 40, passed the GOSTR certificate
	luggage compartment volume (m³)	9	Inner bus model		LCK6127HE
Item		Standard configuration				Optional configuration
Chassis parameters	gearbox	Fast 6DS 180T 6 speed transmission				ZF 6S 1700BO 6 speed box
	clutch	SACHS φ430, single plate, dry
	front axle	independent front axle from Jinben, 6.5T
	rear axle	Dongfeng Dana, 13T
	suspension	full airbag (6 airbags, 6 shock absorbers)
	steering	servo steering gear, steering wheel lock
	brake	double circuit brake; front/gear disc brake; WABCO ABS/ASR, Eddy current retarder
	fuel tank	300L 300L, oil circuit preheating, cold start
	tire	295/80R22.5 (Double Coin)				Michelin
	accumulator/alternator	2×12V/200Ah / 28V/140A 150A
Main components	Bus frame	full bearing structure, concave floor structure				noise absorber for rear bottom panel of the middle gate
	decorative	A type aviation luggage rack, panel with 3 cigarette lighters				B type luggage rack
	door and door pump	Aluminum door, remote controlled door lock, pneumatic front/middle/back passenger door
	side window / windscreen	bonded hollow side window; fully sealed; transparent glasses for driver cab and door window; black glass for others; laminated front glass; toughened rear glass; shade curtain
	rear view system	electrically defrosting rearview mirror; three-lens color LCD screen; monitor (with recording function)
	air conditioner	30000Kcal/h (Bitzer compressor)
	heater system / defroster	SPHEROS 35KW, wall-mounted forced heat sink, 8/4 large-power heat sink, plumbing defroster (air intake from outside)
	audiovisual system	DVD/hard disc machine; 19-inch LCD screen for front door; 17-inch non collapsible LCD screen for middle door; microphone
	lamps	front combination light, rear combination light, brake light
	door	hand-operated side-loading compartment door, aluminum door				bathroom and driver restroom (7.6m3)
	seat	ZTZY3210 luxury seat with adjustable pedal, backrest, and armrest; ZTZY1052 driver seat with airbag; safety belt for each seat, ZTZY2070 tourist guide seat				ISRI NTS armrest for driver seat
	paint	solid color paint				metallic paint, pearl paint
	others	automatic fire extinguishing system for engine compartment; GPS interface; dormer; 2 DS265 ventilators; water tank; LED light; 220V power supply (25-30kw); electronic clock; curtain for side window; 24V converter (220V, 220W); Stainless steel fully enclosed decorative cover for tires				carpet; driver 's rest compartment; bathroom; cloth curtains; shade curtain; water dispenser
Remark: bus model especially for Russia and Kazakhstan alliance area
