Power Press (Nominal force: 160kN~1250kN) Manufacturer

Power Press (Nominal force: 160kN~1250kN)

Request a Quote

View All: http://pressing-machines.com/1-8-power-press.html

Description
The JE21 power press is a general metalworking machine for sheet processing and is suitable for shearing, punching, blanking, bending and shallow drawing operations. A rigid type single revolution clutch is employed on the power press, in conjunction with two-hand operation buttons and foot switch.

Parameters

Type		JE21-16D	JE21-25D	JE21-40D	JE21-63D	JE21-80D	JE21-100D	JE21-125D
Nominal force	kN	160	250	400	630	800	1000	1250
Nominal stroke	mm	2	2.5	4	4	5	6	6
Slide stroke	mm	0-70	0-80	20-120	20-120	10-130	16-140	16-140
Number of strokes	Times/min	130	100	70	60	53	40	40
Max. die height	mm	170	180	220	290	330	320	320
Die height adjustment	mm	30	70	80	80	100	100	100
Distance between slide center and frame (Throat depth)	mm	170	210	250	300	300	380	380
Bolster area (F.B × L.R)	mm	320×480	400×600	480×710	570×760	580×860	710×1100	720×1200
Bolster opening (Upper hole dia. × Depth × Lower hole dia.)	mm	φ100	φ120	φ220×25×φ180	φ200×45×φ180	φ200×45×φ180	φ260×50×φ220	φ260×50×φ220
Bolster thickness	mm	60	70	80	90	100	120	120
Bed opening (Dia. × F.B × L.R)	mm	140×140	180×180	220×220	Steel plate : 220×250	Steel plate : 220×260	260×290	260×290
Bed opening (Dia. × F.B × L.R)	mm	140×140	180×180	220×220	Casting : φ280×220×320	Casting : φ280×220×380	260×290	260×290
Slide area (F.B × L.R)	mm	180×200	210×250	270×320	280×320	280×380	420×560	420×560
Shank hole (Dia.× Depth)	mm	φ40×60	φ40×70	φ50×70	φ50×80	φ60×75	φ60×80	φ60×80
Column spacing	mm	250	330	410	Steel plate 470	Steel plate 450	630	620
Column spacing	mm	250	330	410	Casting 320	Casting 410	630	620
Slide area (F.B × L.R)	kW	2.2	3	4	5.5	7.5	7.5	11
Outline dimension (F.B×L.R×H)	mm	1050×1175×1830	1560×1300×2210	1620×1450×2350	1700×1550×2640	1720×1630×2720	2200×1850×3050	2200×1850×3050
Net weight	kg	1750	2204	3286	Steel plate : 4500 Casting : 5000	Steel plate : 5500 Casting : 6412	9000	9500

Configuration

Crankshaft horizontally placed structure
Crankshaft with stroke adjusting device
Combined dry pneumatic friction clutch
Manual die height adjustment, scale display
JE21-100D and above type employ lifting counterbalance cylinder device
Dual solenoid safety valve
International brand PLC control
Air cushion, electric grease lubrication system are optional

Features of power press

The frame of the power press can incline about 25 degrees to facilitate blanking.
The slide is a cast box-shaped structure with good rigidity.
Rigid overload protector is installed inside the slide. With simple structure, when the slide overloads, the protector is collapsed and destroyed, so as to protect the metal stamping machine and mold from being damaged.
The slide die height implements manual adjustment, with scale display.
Four-sided triangular lengthened guide with easy adjustment
Rigid type single revolution clutch
