Glass Nano Coating Machine
Request a Quote
Surface finishing system for applying nano coatings on glass
Features
- The machine applies a specialized nano coating evenly across the glass surface. Thanks to its precise design, the coating layer is uniform in thickness, ripple-free, and devoid of any streaks, meeting customer requirements to the fullest.
- Suitable for glass coatings with particle sizes of less than 100 nanometers, it works equally well with both water-based and oil-based coatings.
Specifications
| Model | |||
| Working width (mm) | ≤1200 | ≤1500 | ≤2500 |
| Working thickness (mm) | 3-20 | 3-20 | 3-20 |
| Min. working length (mm) | 400 | 400 | 400 |
| Dimensions (L×W×H) | 5000×2300×1500 | 5000×2600×1500 | 5000×3600×1500 |
| Feeding speed (m/min) | 0-5 | 0-5 | 0-5 |
| Feeding power (kW) | 0.75 | 1.5 | 2.2 |
| Total power (kW) | 3.0kW | 4.5kW | 5.9kW |
| Power supply (V/Hz) | 380/50 | 380/50 | 380/50 |
| Coating type | Nano-coating: water-based/oil-based | Nano-coating: water-based/oil-based | Nano-coating: water-based/oil-based |
Applications
Anti-Reflection Coating
This is a deep-processing technology for photovoltaic cover glass. By applying a special nano-solution to the glass surface, it significantly improves the glass's optical properties. This coating reduces surface reflectivity and maximizes light transmission, enhancing the efficiency of solar energy conversion in photovoltaic cells.
Architectural Glass Thermal Insulation Coating
This technology is used for deep processing of architectural glass. The nano-material coating applied to the glass surface is highly effective in insulating against heat and UV rays. It results in energy-efficient glass that shields against UV radiation, ultimately protecting against potential harm to humans.
