CMG1100 Plastic Injection Molding Machine Manufacturer

CMG1100 Plastic Injection Molding Machine

Request a Quote

View All: http://chap-machinery.com/2-1-3-plastic-injection-molding-machine.html

This product has been discontinued and removed from our shelves.

Technical Specifications of Plastic Injection Molding Machine

Description	Unit	CMG1100
Injection Unit
Screw No	/	A	B	C
Screw diameter	mm	35	40	42
Screw length-diameter ratio	L/D	21	19	18
Theoretical injection capacity	cm³	140	187	200
Injection weight(PS)	g	127	170	182
Injection pressure	Mpa	230	176	160
Plasticizing capacity(PS)	g/s	14	16.9	21
Screw rotational speed	rpm	0~180
Clamping Unit
Clamping force	KN	1100
Moving mould distance	mm	300
Tie bar spacing	mm	350×350
Max. mould thickness	mm	420
Min. mould thickness	mm	120
Ejector stroke	mm	100
Ejector force	KN	27
Ejector bar amount	PC	1
Other Unit
Max. pump pressure	MPa	16
Pump motor power	KW	11
Heating power	KW	5.9
External dimension(L×W×H)	mm	4140×1050×1750
Machine weight	kg	2900
Material cylinder capacity	Liter	25
Oil tank capacity	Liter	240

Beginning its business in 2004, CHAP is one of plastic injection molding machine manufacturers and suppliers. We can produce various rubber machineries, such as vacuum rubber vulcanizing machine, C-Frame Transfer type molding machine, hydraulic two-platen plastic injection molding machine, custom rubber machine, and more. Located in Ningbo City, we are surrounded by transportation facilities like highways, airports, and sea ports. This allows us to conveniently transport our products and effectively reduce our customers' freight charges. If you are interested in our products, please do not hesitate to contact us. We look forward to doing business with you.
