Spring Cone Crusher
The spring cone crusher motor leads the eccentric sleeve to rotate; then the fixed and movable eccentric cones swing to crush.
The spring cone crusher's movable cone is supported and hung by aligning bearings.
Adopts water-sealing dustproof device to reinforce the seal.
Spring cone crusher is the most commonly applied mining equipment, used extensively in industries of mineral processing, construction materials, silicate and chemical industry. In plants of small, medium and large scale, the spring cone crusher is mainly used to do primary and secondary cursh on metal ores such as hard and medium hard gold, silver, bronze, lead, zinc, nickel, manganese, iron and molybdenum, and stones such as rock, granite, limestone, barite, quartz, graphite, feldspar, fluorspar.
Type | Model | Crushing Cone Diameter (mm) | Feeding Inlet (mm) | Max. Feeding Size (mm) | Adjusting Outlet Range (mm) | Power (kW) | Capacity (t/h) |
Standard Type | PYB-600/75 | 600 | 75 | 65 | 12~25 | 30 | 40 |
PYB-900/135 | 900 | 135 | 115 | 15~50 | 55 | 50~90 | |
PYB-1200/170 | 1200 | 170 | 145 | 20~50 | 110 | 110~168 | |
PYB-1750/250 | 1750 | 250 | 215 | 25~60 | 155 | 280~480 | |
PYB-2200/350 | 2200 | 350 | 300 | 30~60 | 280 | 500~1000 |
Type | Model | Crushing Cone Diameter (mm) | Feeding Inlet (mm) | Max. Feeding Size (mm) | Adjusting Outlet Range (mm) | Power (kW) | Capacity (t/h) |
Medium Type | PYZ-900/70 | 900 | 70 | 60 | 5~20 | 55 | 20~65 |
PYZ-1200/115 | 1200 | 115 | 100 | 8~25 | 110 | 42~135 | |
PYZ-1750/215 | 1750 | 215 | 180 | 10~30 | 155 | 115~320 | |
PYZ-2200/275 | 2200 | 275 | 230 | 280 | 200~580 |
Type | Model | Crushing Cone Diameter (mm) | Feeding Inlet (mm) | Max. Feeding Size (mm) | Adjusting Outlet Range (mm) | Power (kW) | Capacity (t/h) |
Short Head Type | PYD-600/40 | 600 | 40 | 35 | 3~13 | 30 | 12~23 |
PYD-900/50 | 900 | 50 | 40 | 55 | 15~50 | ||
PYD-1200/60 | 1200 | 60 | 50 | 3~15 | 110 | 18~105 | |
PYD-1750/100 | 1750 | 100 | 85 | 5~15 | 155 | 75~230 | |
PYD-2200/130 | 2200 | 130 | 100 | 280 | 125~350 |
