900W (3100 RPM) Horizontal Travel Drive Motor, PMDC Brushless Motor TF110AH2

900W (3100 RPM) Horizontal Travel Drive Motor, PMDC Brushless Motor TF110AH2
900W (3100 RPM) Horizontal Travel Drive Motor, PMDC Brushless Motor TF110AH2
900W (3100 RPM) Horizontal Travel Drive Motor, PMDC Brushless Motor TF110AH2
Request a Quote
Power
Your Motion

Application: electric material handling equipment

Technical Specifications
Rated Power (W) 900
Rated Voltage(V) 48
No-load Current(A) ≤5.0
No-load Revolution (RPM) 3100
Rated Torque (N•m) 3.1
Max Torque (N•m) 18.0
Rated Revolution (RPM) 2750
Rated Current(A) ≤24.0
Working Cycle (min.) S2-60
Insulation Class F
Protection Level IP44
Length (L/mm) 231

Note: we can customize any brushless DC motors according to your application requirements and working conditions.
