3000kg Wheel Loader
Recommended application
The loading weight of the ZL-30F wheel loader is 3000kg. with mere 5.7m turning radius, it can adapt to the operation in narrow space, and the whole process that the bucket from lifted to lowered, and then to the completion of unloading, only needs 11s, thus the working efficiency is excellent. It can be widely used in the construction of highways, mines, brick and tile factories, urban construction, kilns, stone factories, prefabricated cement parts factories and other agricultural engineering as well as medium and small buildings.
The front bucket adopts the convenient tailgate design to prevent the materials from falling during work. If need to meet different jobs requirements, a fast connector can also be selected to replace a variety of loader mount attachments such as snow bucket, fork, for jobs of different functions.
Technical parameters| Rated loading weight | 3000kg |
| Rated bucket capacity | 1.7m3 |
| Rated power | 92KW |
| Rated speed | 2200rpm |
| Track base | 1800mm |
| Wheel base | 2760mm |
| Min. turning radius(outside of rear wheels) | 5700mm |
| Dump height fully raised | 3020/3250mm |
| Reach fully raised | 1200mm |
| Lifting time Lowering time Unloading time | 11s |
| Max. Bucket breakout, lift cylinder | 138KN |
| Operating weight | 9500kg |
| Overall dimensions (L×W×H) | 7050×2430×3120mm |
| Driving mode | Four-wheel full hydraulic drive |
| Engine model | DEUTZ WP6G125E22 |
| Engine type | In-line arrangement, water cooled , six-stroke diesel engine |
| Engine starting mode | Electric |
| Brake mode | Four-wheel hydraulic spread-shoed brake |
| Warranty | 12 months after received the goods |
| Color | According to the requirements of customers |
| Tyre type | 17.5-25 |
| Shipping port | Qingdao port, China |
| Packing details | Nude package, 1Unit/ 4 0's HQ with disassembled cabin |
| Delivery time | 15 days after confirm the order |
| Supply ability | 100 units per month |
- Cab
- Operating panel
- Steering wheel
- Adjustable seat
Hongyuan Vehicle has been manufacturing super quality wheel loaders, is offering front end loaders for agricultural and heavy construction industry. By changing the associated implements on the loaders, we can offer a wide range of special purpose loaders, like sugar cane grab loader, log grapple loader, rough terrain forklift truck, snow plow, rock breaker and so on. With rich export experience and quality assurance, we provide custom need farming and construction equipment with competitive prices.
