• The front plate can be adjusted up or down according to board thickness.
• Equipped with a high-pressure blower with independently adjustable inverter-controlled air volume.
• The upgraded lead-edge feeder delivers more accurate feeding, significantly improving board adaptability.

Uses a crank-driven platen die-cutting and creasing. The precision worm gear with synchronous belt drive ensures stable motion.

• High-torque pneumatic clutch/brake
• Multicam intermittent indexing mechanism from renowned brands
• Reliable torque limiter (protecting the INDEX system)
• Inclined-pressure micro-adjustment device ( 1.5 mm total adjustment range)
• Durable pre-stretched gripper bar drive chain

These elements ensure accurate and consistent die-cutting performance.

• Both upper and lower frames use a linkage-type stripping mechanism for stable and precise operation.
• The stripping plates improve accuracy, and the central positioning system allows faster plate changes, saving setup time.
• The upper frame features electric lifting.

• A roller-support lifting platform prevents scratching on the sheet surface during delivery.
• Supports quick output of full piles or counted batches.
• The adjustable tension spring chain cushions the idler wheel, greatly reducing the inertial impact during gripper bar reversal and maintaining balanced chain tension.

• Designed with CE-standard dual safety door protection.
• Main components are sourced from established brands such as Siemens, Yaskawa, Schneider, Omron, Mitsubishi, Pizzato, ensuring reliable and stable system performance.
