35000W Traction Motor, PMDC Brushless Motor TR300A
Request a Quote
Your Motion
Application: electric forklift, electric vehicle, elevators, etc.
Features
This traction motor delivers strong overall performance, offering high load capacity within a compact structural design. Its engineering ensures stable, efficient power output to meet the demands of intensive forklift operation.
Applications
It is suitable for various types of electric counterbalance forklifts, providing consistent and reliable traction support across different working conditions.
Technical Specifications
| Matched Motor | PMSM Motor |
| Rated Voltage (V) | 96 |
| Rated Power (W) | 35000 |
| Peak Power (W) | 42000 |
| Rated Torque (N.m) | 66.85 |
| Peak Torque (N.m) | 380 |
| Rated Revolution (RPM) | 5000 |
| Peak Revolution (RPM) | 5500 |
| Rated Efficiency (%) | ≥95 |
| Working Cycle (min.) | S2-60 |
| Insulation Class | H |
| Protection Level | IP55 |
