23000W Traction Motor, PMDC Brushless Motor TR260BXF
Request a Quote
Your Motion
Application: electric forklift, electric vehicle, elevators, etc.
Features
Engineered to handle demanding workloads, the motor combines high load capacity with a compact, efficient design. Its construction supports smooth, dependable power delivery suitable for daily forklift operation.
Applications
Well suited for a variety of electric counterbalance forklifts, offering stable traction and reliable performance across different working conditions.
Technical Specifications
| Matched Motor | PMSM Motor |
| Rated Voltage (V) | 80 |
| Rated Power (W) | 23000 |
| Peak Power (W) | 28000 |
| Rated Torque (N.m) | 45.8 |
| Peak Torque (N.m) | 285 |
| Rated Revolution (RPM) | 4800 |
| Peak Revolution (RPM) | 5000 |
| Rated Efficiency (%) | ≥90 |
| Working Cycle (min.) | S2-60 |
| Insulation Class | H |
| Protection Level | IP65 |
