13000W Traction Motor, PMDC Brushless Motor TR210DXF
Request a Quote
Your Motion
Application: electric forklift, electric vehicle, elevators, etc.
Features
Designed for demanding workloads, the motor offers high load capacity paired with a compact and efficient structure. Its overall design supports smooth, dependable power delivery for everyday forklift operation.
Applications
It is suitable for a wide range of electric counterbalance forklifts, ensuring reliable traction and consistent power across different working conditions.
Technical Specifications
| Model No. | TR210DXF |
| Matched Motor | PMSM Motor |
| Rated Voltage (V) | 80 |
| Rated Power (W) | 13000 |
| Peak Power (W) | 17000 |
| Rated Torque (N.m) | 27.6 |
| Peak Torque (N.m) | 170 |
| Rated Revolution (RPM) | 4500 |
| Peak Revolution (RPM) | 4800 |
| Rated Efficiency (%) | ≥90 |
| Working Cycle (min.) | S2-60 |
| Insulation Class | H |
| Protection Level | IP65 |
