Flouring Machine (Flatbed Preduster)
The flatbed preduster is an automatic flouring machine specially designed for chicken pieces, fish fillets, vegetable slices, meat slices, and similar products. It uses a specialized conveyor belt flouring system to ensure even and reliable powder distribution. Adjustable top and bottom powder layers guarantee consistent coating on both sides, preventing exposed surfaces. The machine enables precise control of powder thickness and can also perform pre-dusting and battering processes meeting diverse food processing requirements.
-
- Burger patties coating
-
- Chicken patty coating
-
- Chicken fillet coating
-
- Popcorn chicken coating
Key Parameters
| Model | | |
| Conveyor speed range | 3-15 m/min (variable frequency) | 3-18 m/min |
| Infeed height | 870-970 mm | 870-970 mm |
| Outfeed height | 1000 ± 50 mm | 1000 ± 50 mm |
| Power | 2.93 kW | 2.93 kW |
| Belt width | 600 mm | 400 mm |
| Dimensions (L × W × H) | 2655 × 1040 × 2150 mm | 2655 × 840 × 2150 mm |
Features
- Motor protection
Built-in temperature sensors and overload protection automatically cut power or reduce speed if the motor is overloaded (e.g., jammed) or overheated, preventing motor damage.
- Emergency stop button
Red button immediately stops the machine in case of operational error.
- Conveyor belt coating
The powder-covered conveyor belt, combined with the scattered top layer, uniformly coats products with pre-dusting or mixed powders, ensuring even coverage without clumping.
