Meat Processing Automatic double clipper for simultaneous sealing of both ends of sausage casing

The sausage clipping machine uses double clipping system to complete the sealing process. Its core mechanism applies clips to both ends simultaneously, ensuring efficient and precise closure.

The sausage clipping machine is suitable for end-sealing and closure operations for various meat products such as ham sausages, pork sausages, chicken sausages, and fish sausages. The double clipping system completes sealing at both ends, and interchangeable tooling allows compatibility with multiple casing sizes and product shapes. The machine can also be integrated with corresponding upstream and downstream equipment.

    1. Pork sausages
    1. Chicken sausages
    1. Fish sausages
Key Parameters
Model HK-160
Clipping speed 80 clips/min
Casing size range Fold diameter 32-130 mm Product diameter 20-85mm
Air pressure 0.5-0.7 MPa
Power 2.7 kW
Voltage 220 V
Weight 420 kg
Dimensions 1150 × 740 × 1580 mm
Features
    1. Control panel

      Digital control interface enabling precise adjustment of clip length, width, and other parameters based on production requirements.

    1. Infeed and discharge ports

      Large-diameter inlet and outlet designed for smooth product transfer without jamming or blockage.

    1. Material construction

      Built from 304 stainless steel, offering easy cleaning, high durability, and reliable food-grade safety.
