Switch Mode Transformer (EFD, EPC Core)
Request a Quote
EFD/EPC power switch mode transformer uses flat ferrite core, extremely suited forproducts with limited height, like ultra-thin switching power, charger, etc.EFD/EPC transformers can simultaneously meet the requirements of powertransformer on high power, ultra-thin volume and temperature rise. Besides, ithas features of high permeability, high magnetic saturation and low magneticcore loss.
Parameters| Type | Pin Number | Dimensions (mm) | ||||
| A | B | C | D | E | ||
| EFD-12 | 8 | 6 | 17 | 20 | 3.0 | 13.5 |
| EFD-15 | 10 | 7.3 | 18.2 | 21.35 | 2.5 | 15 |
| EFD-15 | 10 | 7.5 | 19.3 | 22.6 | 3.0 | 16.7 |
| EFD-20 | 10 | 9.4 | 25.3 | 27.7 | 3.75 | 21.7 |
| EFD-20 | 12 | 9.7 | 24 | 26.8 | 3 | 20 |
| EFD-25 | 10 | 13.4 | 29.7 | 35.4 | 5 | 25 |
| EFD-25 | 10 | 12.6 | 29.7 | 31.5 | 5 | 25 |
| EFD-30 | 12 | 12.6 | 31.6 | 35.5 | 5 | 30 |
