Modular Air Cooled Heat Pump

Modular Air Cooled Heat Pump
Request a Quote

This modular air-cooled heat pump module is an ideal choice for projects with scarce water resources, or no available workshop room. It is especially designed to produce cooling and heating energy, with up to 8 units in each module and a cooling capacity range of 60kW-160kW, and a heating range of 70kW-170kW, with a cool water temperature range of 5°C ~ 20°C and a hot water temperature range of 35~50°C.

This control system incorporates a modular approach, allowing multiple elements to be combined into one unit. With just one system managing multiple units, an effective method of monitoring and controlling the execution of all components is centralized. Meanwhile each units can still be operated independently.

Features
  • Intelligent microcomputer-control system

    The units record the length of time that the compressor is running, and adjust the start and stop times accordingly. When loading and unloading the running load, maintain balance of operation among the compressors and keep wear evened out. Password protection is available in multiple levels all with parameters that can be modified, such as a one-time timer, week timer switch, week timing setup, and holiday setting.

  • Easy configuration

    This system offers up to 16 groups of modules and can be easily adjusted to accommodate many capacities. Its modular units and flexible installation options make it suitable even in small areas - it can be set up in a variety of different places and save precious space. Expanding the system's capacity is a breeze, allowing for gradual investment.

  • Reliable operation

    The unit consists of multiple independent refrigerant systems, none of which impair the performance of the other when activated. Even when an alarm shutdown occurs in one system, it won't impact any of the other circuits. Should a module alarm & halt, it does not interfere with the operation of the other modules.

  • Energy efficient

    This air conditioning unit employs a branded compressor and expansion valve and a high-efficiency heat exchanger made in-house to provide a quiet and effective operation. The heat exchanger, which is the most important component, affects the unit’s quality and shelf-life. The heat exchanger tube, the unit’s only external part in contact with the air, should have the right thickness and made of an appropriate material, dependent on the quality of the air and water in the area of use.

Specifications

Modular Air Cooled Heat Pump

Refrigerant: R410a
Power supply: 380V-3N-50Hz

Model Nominal cooling Nominal heating Compressor quantity Condenser Evaporator Noise level dB(A) Weight kg
Cooling capacity kW Compressor power input kW Heating capacity kW Compressor power input kW Structure Air flow ×1000m3/h Power kW× unit Pipe diameter (inlet/outlet) in Water pressure drop kPa Chilled water flow m3/ h Hot water flow m3/h
20STB-V25AHDM14 60 19 66 19 2 Copper tube with corrugated aluminum fins 29 1.2×2 2" 28 10 11 68 830
20STB-V30AHDM14 78 24 84 24 2 40 2×2 2-1/2" 30 13 14 69 1080
20STB-V50AHDM14 120 38 132 38 4 58 1.2×4 2-1/2" 33 21 23 70 1660
20STB-V60AHDM14 156 48 168 48 4 80 2×4 2-1/2" 35 27 29 71 2160

Notes:

  • 1. Rated cooling capacity standard: air dry / wet bulb temperature 35℃ /24℃, chilled water inlet/outlet temperature 12℃ /7℃, fouling factor 0.088 ㎡•℃ /kW;
  • 2. Rated heating capacity standard: air dry / wet bulb temperature 7℃ /6℃, hot water inlet/outlet temperature 40℃ /45℃;
  • 2. Chiller water temperature range: 5℃ ~20℃;
  • 4. Hot water temperature range: 35℃ ~50℃;
  • 5. Cooling ambient temperature range: 15℃ ~43℃, heating ambient temperature range: -10℃ ~43℃;
  • 6. Available voltages: 220V, 380V, 400V, 415V, 440V, 460V
Optional
  • Heat recovery module

    Heat recovery technology enables customers to reap the benefits of recycled heat energy, providing a steady stream of free hot water in the temperature range of 45 to 65°C. This renewable and cost-effective resource is perfect for hotels, hospitals, schools, and other large public institutions.

  • Frequency conversion

    This unit features a frequency converter, allowing for frequency conversion operation of the compressor that can greatly increase energy efficiency when working at partial load. With this upgrade, its energy efficiency is drastically improved at partial loads, making it a truly transformative double efficient unit capable of reaching full load efficiency (COP) as well as a intergrated part-load value (IPLV).
