TIG AC/DC SERIES TIG Welder, Tungsten Inert Gas Welding
Features
- The TIG AC/DC series TIG welder features a square wave output and a stable arc.
- AC/DC TIG welding makes it especially useful for aluminum material welding.
- A foot pedal controller is an optional equipment piece.
- Built-in alarming and protective circuits are provided to prevent over current, over heat, over voltage, low voltage, and other problems, ensuring safe operation.
- High duty cycle.
- This equipment is suitable for welding a variety of metallic materials, including aluminum, aluminum alloy, carbon steel, stainless steel, copper, and more.
Parameters
| Model | WSE-200 | WSE-250 | WSM-200S |
| Power Voltage(v) | 230 | 230 | 230 |
| Input Voltage Frequency(hz) | 50/60 | 50/60 | 50/60 |
| Output Current Range(a) | 10-200 | 10-250 | 10-200 |
| Arc Strike Way | HF | HF | HF |
| NO-load Voltage(v) | 56 | 56 | 56 |
| Duty Cycle(%) | 60 | 60 | 40 |
| Insulation Class | F | F | F |
| Efficiency（%） | 80 | 80 | 80 |
| Weight(kg) | 22 | 23 | 17 |
| Measurement(mm) | 600*440*415 | 600*440*415 | 585*320*420 |
| Protection Class | IP21s | IP21s | IP21S |
| Usable Electrode(mm) | / | 1.6-4.0 | 1.6-4.0 |
| Cod.(no) | 880038 | 880039 | 880040 |
