TIG AC/DC SERIES TIG Welder, Tungsten Inert Gas Welding
Features
- This TIG welder features multiple functions: AC/DC MMA, and AC/DC pulse TIG.
- It features a quality square wave power supply and a stable arc.
- This welder features an excellent oxide film cleaning ability, a continuously adjustable cleaning width, and a bright, beautiful weld seam. It is especially suitable for welding aluminum, magnesium, and alloy materials.
- It is easy to start the arc, and this equipment features a stable welding current, a quick dynamic response, and a focused arc.
- AC welding is carried out for a beautiful welding formation.
- This TIG welder comes with a comprehensive range of protection functions, including over-current, overheating, over voltage and under voltage, ensuring operation is safe and reliable.
- The panel comes with remote control and an optional foot switch.
- The TIG220P features an added gas supply before welding, and features an adjustable time using an easy to use knob.
Parameters
| Model | TIG-200P | TIG-220P | WSME-315 |
| Power Voltage(v) | 230 | 230 | 380 |
| Input Voltage Frequency(hz) | 50/60 | 50/60 | 50/60 |
| Output Current Range(a) | 10-200 | 10-220 | 10-315 |
| Arc Strike Way | HF | HF | HF |
| NO-load Voltage(v) | 56 | 56 | 60 |
| Duty Cycle(%) | 40 | 40 | 60 |
| Insulation Class | F | F | F |
| Efficiency（%） | 80 | 80 | 80 |
| Weight(kg) | 22 | 22 | 22 |
| Measurement(mm) | 600*440*415 | 600*440*415 | 630*340*680 |
| Protection Class | IP21s | IP21s | IP21S |
| Usable Electrode(mm) | 1.6-4.0 | 1.6-4.0 | 1.6-5.0 |
| Cod.(no) | 880041 | 880042 | 880043 |
