TIG-SERIES TIG Welder
Request a Quote
Welding machine manufacturerSince 1988
TIG-SERIES TIG Welder, Tungsten Inert Gas Welding
Features
- This TIG welder is especially useful for welding stainless steel.
- The TIG series TIG welder is lightweight and easy to carry.
- HF arc-starting.
- The TIG series features a smooth and beautiful welding appearance.
Parameters
| Model | TIG-160 | TIG-200 | TIG-160 | TIG-200 |
| Power Voltage(v) | 230 | 230 | 120 | 120/230 |
| Rated Input Power(kva) | 3.2 | 4.5 | 3.2 | 4.5 |
| Input Voltage Frequency(hz) | 50/60 | 50/60 | 50/60 | 50/60 |
| No-load Voltage(v) | 43 | 43 | 43 | 43 |
| Output Current Range(a) | 10-160 | 10-200 | 10-150 | 10-150/10-200 |
| Rated Output voltage(v) | 16.4 | 18 | 16 | 18 |
| Rated Duty Cycle(%) | 60% | 60% | 60% | 80%/60% |
| Weight(kg) | 11 | 11 | 11 | 11 |
| Measurement(mm) | 460*270*345 | 460*270*345 | 460*270*345 | 460*270*345 |
| Cod.(no) | 880001 | 880002 | 880003 | 880004 |
