4 Wheel Drive Backhoe Loader
- Sliding boom
- The boom rotates at 180 degrees
Recommended application
HY-15-10 4 wheel drive backhoe loaders not only have all the functions that small excavators and loaders possessed, but also can significantly expand the digging range with the sliding boom and the efficiency of digging is up to 20-40m3/h. According to the different demands of users, a variety of optional equipment can be added to implement different functions.
This series of loaders can be widely used in the construction and maintenance of urban and rural highways, cable laying, electric power and airport engineering, municipal construction, irrigation and water conservancy construction, rural housing construction, mining and exploration, etc.
Basic parameters| Total weight | 3700kg |
| Gradeability | 0.25 |
| Walking speed | ≤20km/h |
| Distance between axles | 1725mm |
| Min. ground clearance | 230mm |
| Overall dimension(L×W×H) | 5400×1620×2650 |
Detailed information
1. technical specification of excavator| Bucket capacity | 0.2m3 |
| Working efficiency | 20-40m3/h |
| Working times | 3-5 times/min |
| Max. hauling force | 23kN |
| Max. swing angle of boom | 180° |
| Max. digging depth | 2100mm |
| Max. digging height | 4000mm |
| Max. digging radius | 4500mm |
| Max. dumping height | 3000mm |
| Rated loading mass | 1000kg |
| Lifting time of movable arm | 4.5s |
| Lowering time of movable arm | 3s |
| Summational time | 10s |
| Max. ground clearance | 10.5kN |
| Max. Dumping height | 2400mm |
| Max. Dumping distance | 900mm |
| Min. Ground clearance | 3500mm |
| Model | 4L68 |
| Rated power | 51HP |
| Working pressure | 16Mpa |
| Max. flux | 25ml/r |
Large tyres1. 51HP large torque engine combined with four wheel drive to ensure strong driving force.
Standard bucket2. The prepositive standard bucket has a capacity of 0.2m3 and high digging efficiency.
3. The enlarged cab is made of safety glass, spacious and bright, and equipped with adjustable seat and operating handle, making the driving experience more comfortable.
4. The microcomputer controlled worktable makes the water temperature, oil temperature, current and work timing all be clear at a glance.
5. The rotatable oil tank is more convenient for refueling.
6. Using high quality hydraulic parts with long service life and fast working speed.
7. The steering and walking of the loader are hydraulically controlled, and equipped with advanced variable motor and stepless speed change device, the operation is easy and convenient.
