- Product Standard: Q/EFR/J 1.1-2019
- Certifications: CE certificate
- Diameter: ⌀80±2 (mm)
- Rated Power: 70-120 (W)
- Max Power: 85-140 (W)
A Series CO₂ Laser Tube
Request a Quote
- Parameters
- Features
- Application
- Operating Condition
- Package Size
Parameters
| Model | Length(mm) | Diameter(mm) | Rated Power(W) | Max Power(W) | Warranty period(days) | Catalyst |
| | 1100±20 | Φ80±2 | 70 | 85 | 540 | Yes |
| | 1250±20 | Φ80±2 | 80 | 90 | ||
| | 1400±20 | Φ80±2 | 90 | 110 | ||
| | 1650±20 | Φ80±2 | 120 | 140 | 360 |
Features
- The catalyst-containing laser tube features non-tunable cavity and advanced glass-to-metal sealing technology with a laser life of 540 days.
- Upgraded laser lens inside the cavity offers good spot quality, making CO₂ the laser tube reach the quasi-TEM00 fundamental mode, with higher accuracy.
- This laser equipment accessory features excellent beam quality, small spot, and fast response speed, making it widely used in laser marking machines and engraving machines.
- The CO₂ laser tube has passed the verification of many enterprise customers, because the working mode is stable, and the cost performance is extremely high.
- It is equipped with a dust cover design for the laser light outlet, which is suitable for a variety of industrial environments.
Application
EFR's high power, durable and stable CO₂ laser tubes have a small light spot and can be used as laser cutting machine accessories, laser engraving machine accessories, and laser marking machine accessories. As they play an important part in cutting, engraving and marking of leather products, car seats, clothes, paper, and other products in the advertising, packaging, craft processing, decorative construction material industries, our laser consumables are widely recognized and popular among numerous manufacturers of laser machines.
- Laser Engraving Fabric
- Laser Cutting Metal
- Laser Engraving and Cutting Wood
- Laser Cutting Acrylic
- Laser Engraving and Cutting Acrylic
- Laser Cutting Paper
Operating Condition
- Cooling method: Water cooling
- Cooling liquid: clean water
- Flow rate: 3-5L/min
- Standard water temperature: 10℃-40℃
- Ambient temperature: 2℃ -40℃
- Ambient humidity: 10-60%
Package Size
| Model | Packing | Dimensions (L*W*H)(cm) | Net Weight (kg) | Gross Weight (kg) |
| | Single Packing | 139*26*24 | 2.2 | 5.16 |
| | Single Packing | 154*26*24 | 2.4 | 5.7 |
| | Single Packing | 169*26*24 | 2.9 | 6.4 |
| | Single Packing | 194*34*31 | 3.3 | 8.7 |
Package
For more information,please download
