NB-S SERIES MIG Welder
Request a Quote
Welding machine manufacturerSince 1988
NB-S SERIES MIG Welder，Metal Inert Gas Welding
Features
- The NB-S series MIG welder uses an IGBT soft switch, ensuring the equipment reliability.
- The arc is adjustable.
- There is very little spatter, with a smooth welding appearance.
- Adjustment of the welding current and voltage are separate.
- Suitable for CO2/MIG welding.
Parameters
| Model | NB-350S | NB-500S |
| Power Voltage(v) | 380 | 380 |
| Frequency(hz) | 50 | 50 |
| Rated Welding Current(a) | 350 | 500 |
| No-load voltage (v) | 55 | 66 |
| Current Range (a) | 60-350 | 80-500 |
| Rated Input Power(kva) | 16 | 28 |
| Rated Duty Cycle( %) | 60 | 60 |
| Weight(kg) | 82 | 93 |
| Measurement（mmm） | 690*430*1010 | 690*430*1010 |
| Wire Diameter(mm) | 0.8~1.2 | 0.8~1.6 |
| Usable Electrode(mm) | 1.6-8.0 | 1.6-8.0 |
| Cod.(no) | 870030 | 870031 |
