Liquid Soap Detergent Filling Line
- Suitable for filling: Viscous liquids such as liquid soap, detergent, laundry liquid, hand washer, fabric softener, clothes softener, super gel, etc.
- Filling range: 30ml -200ml/ 100ml -2000ml/ 300ml -5000ml
- Filling system: Piston type
- Accuracy: 0.2%
- Capacity: 1000-6000BPH
Automatic packaging of daily chemicals, food, chemicals, pesticides, oils and other liquids. Automatically complete bottle unscrambling, filling, capping, labeling, QR code, unpacking, packing, sealing, and palletizing, equipped with an integrated environmental protection cover. In line with the three standards of safety, environmental protection and intelligence, the production process is automatically coordinated, stable and efficient.
Intelligent bottle unscrambler, intelligent filling and capping integrated machine, online checkweighing and rejecting device, aluminum foil sealing machine, inkjet printer, two-dimensional code traceability system, high-speed unpacking machine, partition machine, intelligent packing machine, online inspection Heavy rejection machine, intelligent stacker, robot palletizer.
- This line is suitable for the packaging of pesticides, lubricating oils, food edible oils, sauces, condiments, wine, paints, daily chemical detergents, conditioners, shower gels, disinfectants, detergents and other products.
- The whole line can be operated by 2-3 people, which reduces labor intensity and labor cost.
- The filling speed of the whole line is 1000-6000 bottles/hour, which can be customized according to requirements.
- The average filling accuracy is ±0.2%, the accuracy is accurate, and unnecessary waste is reduced.
- The whole line is made of stainless steel, with beautiful appearance and high appearance. Customers can visit it.
| Model | |||||
| Dimensions | 2200(L)x1100(W)x2200(H) mm | 2300(L)x1100(W)x2200(H) mm | 2400(L)x1100(W)x2200(H) mm | ||
| Filling head | 6 | 8 | 10 | 12 | 16 |
| Capacity (1L) | 1800B/H | 2400B/H | 3000B/H | 3600B/H | 4800B/H |
| Power | 2.2kW | 2.2kW | 2.2kW | 3kW | 3kW |
| Suitable bottle | Diameter: ⌀ 40mm - ⌀ 100mm, height: 80mm-280mm | ||||
| Neck diameter | ⌀ 18mm | ||||
| Filling range | 50ml-1000ml | ||||
| Air pressure | 0.6Mpa-0.8Mpa | ||||
| Power supply | 380V, 50Hz/60Hz | ||||
| Model | | |
| Dimensions | 2200(L)*1100(W)*2200(H) mm | 2400(L)*1100(W)*2200(H) mm |
| Filling head | 6 | 8 |
| Capacity (1L) | 1800B/H | 2200B/H |
| Capacity (5L) | 700B/H | 1000B/H |
| Power | 3kW | 4kW |
| Suitable bottle | Round bottle: Height: 100-320mm Diameter: ⌀ 60-140mm Flat bottle: Length: 100-200mm Width: 40-80mm Height: 150-300mm Neck diameter: ≤⌀30mm, ≥⌀3,0 customized | |
| Filling range | 1000ml-5000ml | |
| Air pressure | 0.6Mpa-0.8Mpa | |
| Power supply | 380V, 50Hz/60Hz | |
