Application
The single column test machine was developed to measure the mechanical and physical characteristics of materials in various states, including stretching, compression, cutting, tearing, striping, etc. It is suitable for use with various materials and product types, including rubber, plastic, waterproof materials, protective materials, yarn, fiber, wire, cable, tape, and much more.

Specification

Model GT-UA03
Capacity 50N, 100N, 200N, 500N, 1KN, 2KN, 2.5KN, 5KN
Display Computer display
Force Resolution 1/100,000
Force Accuracy ≤+/-0.5%
Stroke Range 1000mm
Stroke Resolution 0.001 mm
Test Speed 0.001-1000mm/min can set on display, with up & down fast adjustment button of grips
Force Unit Switch Kgf, N, Ibf, g, ton, Mpa
Stop Mode Overload stop, emergency stop button. specimen damage automatic stop
Machine Drive Servo motor drive, synchronous wheel and precision ball screw drive
Power 120W
Power Supply AC 220V 50-60HZ 10A
Dimensions Approx 50x40x145 cm
Weight 60kg

Standards
EN ISO 20344 section 7.2 GB/T20991 section 7.2
EN ISO20347 section 5.7.3 AS/NZS 2210.2 section 7.2
SATRA TM5, TM53, TM52, TM51, TM108, TM113, TM117, TM118, TM120, TM123, TM149, TM162, TM401, TM 411,TM 410,
ASTM D751/ 2209 / 412 / 624 / D 882 / 5748, FIA 1206,
BS5131- 3.7, 5.11, 5.13 , BS 5131-2.6
ISO22650, ISO 19958, ISO 3377-1, ISO 3377-2, ISO 11644, ISO 20866, ISO20867, ISO19957, ISO20874, ISO20344-5.2.4, ISO 20345-5.3.1.2, ISO17698, ISO20875, ISO22777, ISO22776, ISO22654, ISO20863, ISO20876, ISO17695, ISO17697, ISO34-1 ,ISO36, ISO37, ISO 17708,
ISO 17696, ISO17706
AS/NZS 2210.2-5.2.4
DIN 53331,
GB/T3903.8, GB/T3903.9, GB/T3903.14, GB/T3903.20, GB/T3903.21, GB/T3903.22,
GB/T 3903.23, GB/T 3903.24, GB/T 3903.25, GB/T 3903.26, GB/T 3903.29, GB/T3903.32,
GB/T 3903.39, GB/T 3903.40, GB/T 3903.43, GB/T 4689.20, GB/T20991-5.2.4,
GB 21148-5.3.1.2, GB/T 17928, GB/T529, GB/T528, GB/T532, GB/T21396
QB/T11413 ,QB/T 2711 ,QB/T2675, QB/T2883, QB/T4118,QB/T4198
HG/T 2726, HG/T 2877, HG/T4805
