Frame Plate Rubber Vulcanizing Machine
Request a Quote
Applications
The frame plate rubber vulcanizing machine is designed for the production of rubber tires and other rubber and silicone products. The vulcanizing machine is used for the manufacturing of hand cart tires, rubber wheels, and tractor tires, along with O-rings, sealing elements, textile equipment, rubber rollers and many more products.
Product parameters
| Model | |
| Nominal clamp force (MN) | 5.60 |
| Hot plate dimension (mm) | 1300x2000 |
| Hot plate spacing (mm) | 400 |
| Hot plate layers | 1 |
| Plunger stroke (mm) | 400 |
| Hot plate pressure per unit area (MPa) | 2.2 |
| Main motor power (Kw) | 8 |
| Machine dimension (mm) | 2000x1860x2500 |
| Model | |
| Nominal clamp force (MN) | 8.00 |
| Hot plate dimension (mm) | 1500x1500 |
| Hot plate spacing (mm) | 800 |
| Hot plate layers | 1 |
| Plunger stroke (mm) | 800 |
| Hot plate pressure per unit area (MPa) | 3.6 |
| Main motor power (Kw) | 16.5 |
| Machine dimension (mm) | 2200x2200x4300 |
| Model | |
| Nominal clamp force (MN) | 15.00 |
| Hot plate dimension (mm) | 1500x2500 |
| Hot plate spacing (mm) | 400 |
| Hot plate layers | 1 |
| Plunger stroke (mm) | 400 |
| Hot plate pressure per unit area (MPa) | 4.0 |
| Main motor power (Kw) | 11 |
| Machine dimension (mm) | 3000x2500x3300 |
| Model | |
| Nominal clamp force (MN) | 20.00 |
| Hot plate dimension (mm) | 2000x2000 |
| Hot plate spacing (mm) | 400 |
| Hot plate layers | 1 |
| Plunger stroke (mm) | 400 |
| Hot plate pressure per unit area (MPa) | 5.0 |
| Main motor power (Kw) | 11 |
| Machine dimension (mm) | 3600x3000x3300 |
Product description
- Custom service. The hot plate dimension, layers, pressures and other parameters of vulcanizing machine can be customized to meet client demands.
- This series of vulcanizing machine can be equipped with a PLC automatic control system for automatic exhaust functionality. The exhaust period, interval and times can all be freely adjusted. The machine also has the function of automatic pressure compensation to compensate the decrease of the pressure during vulcanization.
- Installation consulting service. Some large-scale vulcanizing machines need to be disassembled into several boxes before delivery. We will take photos of these processes for client convenience. As for large-scale and complex vulcanizing machines, we recommend our clients to use our professional assembly workers for onsite assembly and installation.
Our advantages
- Frame plate rubber vulcanizing presses are mainly nonstandard types. It can be customized to meet client demands.
- Before delivery, the machine is under a pressure that is over 1.3 times higher than nominal pressure. During a pressure test, the given pressure is 1.25 times of nominal pressure and needs to last 24 hours.
- Every year Shun Cheong manufactures many types of frame plate rubber vulcanizing presses. The maximum width of hot plate can be up to 3600mm and the pressure can be up to 134.00MN. Recently, with the development of military industries, the demands for large-scale vulcanizing presses are rapidly increasing. Our recent product, the XLB-3000X3000/27.00MN vulcanizing press is manufactured to produce certain kinds of military products.
