C-XLB-D550X600 2000KN Double Layer Plate Rubber Vulcanizing Machine and Rubber Press

C-XLB-D550X600 2000KN Double Layer Plate Rubber Vulcanizing Machine and Rubber Press
C-XLB-D550X600 2000KN Double Layer Plate Rubber Vulcanizing Machine and Rubber Press
C-XLB-D550X600 2000KN Double Layer Plate Rubber Vulcanizing Machine and Rubber Press
C-XLB-D550X600 2000KN Double Layer Plate Rubber Vulcanizing Machine and Rubber Press
Request a Quote

Product introduction
C-XLB-D550×600/2000 Double layer plate rubber vulcanization machine heating plate size is 550m×600 m and clamping force is 2000 KN.

Applications
CHAP plate rubber vulcanizing machine is the main forming equipment for various rubber molded products and non-molded products. Typically, it is suitable for compression moulding of thermoset plastics, foam, resin, bakelite, thin metal and construction materials.

Technical Specifications of Plate Rubber Vulcanizing Machine

C-XLB-D550×600/2000
Clamping force 2500 KN
Clamping stroke 300 mm
Rapid clamping speed ≥50 mm/s
Heating plate size 550mm×650mm
Heating plate spacing 180~480 mm
Max operating temperature of heating plate 250 ℃
Number of working layer 1 layers
Spacing /
Max ejector force 60 KN
Motor power 5.5 KW
Heating power 18.3KW
External dimension (LxWxH) 1900mm×2350mm×2100mm
Oil tank capacity 250 L

CHAP is a major manufacturer and supplier of plate rubber vulcanizing machine in China. Our vacuum rubber vulcanizing machine, custom rubber machine, tire valve vulcanizing machine, rubber injection molding machine, etc. are produced in strict compliance with the international standard. In addition, our company is located in Ningbo City which provides us with convenient transportation. In addition, the abundant raw materials and labor forces here can help largely reduce our production costs. Therefore, we can provide clients with quality products at competitive prices. If you are interested in our rubber machineries, please do not hesitate to contact us. We will offer quality products and services to you. We look forward to cooperating with you.
