Hydraulic Clamp System, FY Series

Request a Quote

View All: http://moldpresscn.com/3-3-fy-series-hydraulic-clamp-system.html

The FY series hydraulic clamp system is primarily used for clamping molds with a T-slot clamp, thus reducing the time needed to change molds. Compared to other hydraulic clamp systems, work support is its most attractive feature, as it saves a significant amount of installation space.

The FY series hydraulic clamp systems are more often used for stamping molds, with matched equipment including a stamping machine, oil hydraulic machine, and more.

Technical parameter

Optional type

FY2

Clamping force (25MP): 20 kn
Stroke X: 7 mm
Clamping stroke Y: 3 mm
Reserved secure stroke Z: 4 mm

FY4

Clamping force (25MP): 40 kn
Stroke X: 7 mm
Clamping stroke Y: 3 mm
Reserved secure stroke Z: 4 mm

FY6

Clamping force (25MP): 60 kn
Stroke X: 8 mm
Clamping stroke Y: 4 mm
Reserved secure stroke Z: 4 mm

FY10

Clamping force (25MP): 100 kn
Stroke X: 8 mm
Clamping stroke Y: 3 mm
Reserved secure stroke Z: 5 mm

FY16

Clamping force (25MP): 160 kn
Stroke X: 8 mm
Clamping stroke Y: 3 mm
Reserved secure stroke Z: 5 mm

FY25

Clamping force (25MP): 250 kn
Stroke X: 8 mm
Clamping stroke Y: 3 mm
Reserved secure stroke Z: 5 mm

Type	Clamping force(25MP)	Whole stroke	Clamping stroke	Reserved secure stroke	Hydraulic clamping cylinder volume	Weight
Type	KN	mm	mm	mm	cm3	kg
FY2	20	8	4	4	6.5	2
FY4	40	8	3	5	15	4
FY6	60	8	3	5	22	6
FY10	100	8	5	5	33	8
FY16	160	8	5	5	55	10
FY25	250	8	5	5	85	18

Type selection
Users can choose the corresponding clamp type and number according to your equipment needs.

Type of the hydraulic clamping system			a(H7)	b	c	d
FW2	FW2-S	FY2	18	30 20	14 10	19±0.2
FW4	FW4-S	FY4	22	36 20	16 10	25±0.2
FW6	FW6-S	FY6	22	36 20	16 10	25±0.2
FW10	FW10-S	FY10	22	36 20	16 10	25±0.2
FW16	FW16-S	FY16	28	46 20	20 20	32±0.2
FW25	FW25-S	FY25	36	60 20	30 20	41±0.2
FW50	FW50-S	/	42	68 20	30 20	47±0.2

Dimensions

Specification	M	N	Rc	L	J	K	H(Standard)
FW2	50	55	1/8	12	18	38	25
FW4	76	65	1/4	15	25	55	30
FW6	80	70	1/4	15	30	64	30
FW10	100	75	1/4	15	40	78	40
FW16	130	80	1/4	15	50	88	50
FW25	150	105	1/4	15	60	98	50

Note: H is the thickness of mold base plates that are paired with standard hydraulic clamps. Customization is available upon request.

Features

Electrical system equipped with an OMROM programmable controller, ensuring a user-friendly interface and multi-layer safety protection.
