Underground Dump Truck, FK8-25T
Request a Quote
Basic Information
-
- Curb weight
- 13760kg
-
- Max. traction force
- 210kN
-
- Dump box volume
- 10m3
-
- Approach anglex
- 25°
-
- Rated load
- 25000kg
-
- Rated power
- 243kW
Technical Specification - Dimensions (L×W×H):7900×2500×2720mm
- Curb weight: 13760kg
- Dump box volume: 10m3
- Rated load: 25000kg
- Max. traction force: 210kN
- Max. height of dump box (dumping position): 6150mm
- Max. height of dump box (tramming position): 1200mm
- Min. ground clearance: 320mm
- Min. turning radius: 11000mm
- Approach angle: 25°
- Gradeability (heavy load): 14°
- Max. dumping angle: 46°
- Dump box lifting time: 35s
- Dump box descending time: 15s
- Max. travel speed (forward): 55Km/h
- Max. travel speed (reverse): 12.5Km/h
- Diesel engine brand: Yuchai Engine
- Diesel engine power: 243kW
