LZF25 Flow Diverter Valve
Request a Quote
- Flow diverter valve can be used to divert flow in three pump hydraulic systems.
- Diverter valve is manufactured in multiple circuits for a better control of fluid flow.
- Control valve is easy to install.
Applications
- Wheel loader
- Excavator/loader
- Material handling machinery
Parameters
| Rated pressure (MPa) | 25 |
| Rated flow (L/min) | 160 |
| Deferential control pressure (MPa) | 0.9 |
| Hydraulic oil | Mineral oil (HL, HLP) in accordance with DIN 51 524 |
| Fluid temperature range (℃) | －20～100 |
| Viscosity range (mm2/s) | 10～380 |
| Fluid cleanliness | Not lower than GB/T 14039-93 level 19/16 or NAS 1638 level 10 |
| Weight (kg) | 21 |
Professional supplier engaged in the R&D, manufacturing, and sales of various hydraulic components
Annual production capacity of 250,000 sets of hydraulic components
Over 30 series and over 200 varieties and specifications to meet the specific needs of our clients
