KR18 Roll Forming Machine

KR18 Roll Forming Machine
KR18 Roll Forming Machine
Request a Quote
List of accessories for BOHAI KR18
Name Amount
Decoiler 1
Sewing machine 2
Collection table 1
Clamp 4
Bearing ( 208#) 4
Drive chain 3(run)
Chain link 3
Half Section 3
Super Pliers 1
Metal Scissors 1
Wrench 1
Travel Switch 1 ( set)
Main Technical Parameter
  • Chassis: 250mm U-steel structural steel welding
  • Forming type: Chain drive
  • Diameter of axle:¢65mm
  • Chain: 16A
  • Forming motor power: 5.5kw
  • Forming speed: 8-15m/min
  • Forming rollers: 12 steps
  • Roller material: 45#steel, coated hard chrome
  • Thickness of coated hard chrome: 0.05mm
  • Hydraulic station motor: 3kw
  • Hydraulic oil pump: Gear pump
  • Cutting type: Hydraulic cutter
  • Material of cutting part: Cr12, heat treatment HRC58℃-60℃
  • Thickness of coils: 0.5-1.3mm
  • Length scale precision: ±2mm
  • Transducer: YASKAWA
  • Controlling system: PLC, touch screen
  • Power: 220V 60HZ 3 phase, 15KW electric generator
  • Size: 5500mmx1500mmx2000mm
  • Weight:5 tons
