LPG-150

Spray drying system for converting liquids into dry powder
  • 24 to 42 kg/h Output
  • Steam Electric Power Heating Method

The micro mist spray dryer is a highly efficient drying system that uses advanced atomization technology to transform liquid materials into fine droplets. These droplets come into contact with hot air, quickly evaporating moisture and producing dry powder within a short time. This process ensures high-quality, stable products suitable for a variety of industries.

Key features
  • Achieves a final moisture content of 3-5%, ensuring the stability and storability of the dry powder
  • Utilizes a combination of steam and electricity as the heat source to reduce energy consumption and enhance production efficiency
  • Inlet temperature ranges from 160-220°C, and outlet temperature ranges from 80-100°C, allowing for adjustable temperature settings to optimize drying performance for different materials as required.
Applications
  • Pharmaceutical industry: Used for drying penicillin, vaccines, and other drugs to preserve their active ingredients
  • Food industry: Widely applied for drying food additives and nutritional components, improving their shelf life and taste
  • Chemical industry: Suitable for drying chemical raw materials like phenolic resins and catalysts, ensuring uniformity and quality
  • Ceramic industry: Ideal for drying ceramic materials such as alumina and carbides, enhancing their strength and stability
Specifications
Model LPG-150
Evaporative Capacity 150kg/h
Liquid Processing Capacity 150-203kg/h
Output of Processed Product 24-42kg/h
Solid Content of Liquid 18-30%
Water Content of Processed Product 3-5%
Power 204kW
Heating Method Steam electric power
Inlet Air Temperature 160-220℃
Outlet Air Temperature 80-100℃
Machine Dimensions (L×W×H) 12200×7000×10750mm
