Plastic Material Dryer, NHD
Request a Quote
This plastic material dryer is designed for drying large-scale industrial plastic materials. It is constructed with conical structure, the maximum capacity up to 8000L, fully satisfying the needs of large-batch production.
Features:
- Stainless steel double-walled insulation
- Designed with air pipe to discharge air through bottom of hopper, evenly dispersing hot air to ensure smooth flow of materials
- Precise PID temperature control
- Made of stainless steel, robust and durable
- Equipped with over-temperature control
- Automatic turn-on /turn-off can be set within a week, more power efficient
Specification:
| Model | Electric heating (kw) | Blower | Hopper capacity (L) | Dimension (mm) | Height H2 | Net weight (kg) |
| (kw) | H*W*D | |||||
| NHD-20U | 2.4 | 0.135 | 20 | 1275*610*470 | 1275 | 40 |
| NHD-40L | 2.4 | 0.135 | 40 | 1280*658*587 | 1280 | 45 |
| NHD-80L | 4 | 0.17 | 80 | 1534*760*655 | 1534 | 50 |
| NHD-120L | 4 | 0.17 | 120 | 1618*870*700 | 1618 | 60 |
| NHD-160L | 5.4 | 0.2 | 160 | 1710*922*762 | 1710 | 90 |
| NHD-230L | 7.2 | 0.33 | 230 | 1860*880*700 | 1860 | 100 |
| NHD-300L | 10 | 0.33 | 300 | 1860*880*700 | 1860 | 130 |
| NHD-450L | 12 | 0.41 | 450 | 1860*880*700 | 1860 | 160 |
| NHD-600L | 15 | 0.41 | 600 | 2350*930*1150 | 2470 | 200 |
| NHD-750L | 20 | 0.75 | 750 | 2350*1250*1040 | 2780 | 220 |
| NHD-900L | 20 | 0.75 | 900 | 2500*1550*1050 | 2900 | 250 |
| NHD-1200L | 22 | 1.5 | 1200 | 3230*1680*1160 | 3230 | 380 |
| NHD-1500L | 36 | 1.5 | 1500 | 3300*1420*1850 | 3000 | 495 |
| NHD-2000L | 36 | 2.2 | 2000 | 3650*1420*1850 | 3450 | 570 |
| NHD-2500L | 48 | 3.7 | 2500 | 4100*1420*1850 | 3730 | 620 |
| NHD-3000L | 64 | 5.5 | 3000 | 4100*1420*1850 | 3820 | 700 |
| NHD-3500L | 64 | 5.5 | 3500 | 4310*1770*1400 | 4800 | 785 |
| NHD-4000L | 64 | 5.5 | 4000 | 4050*1980*1600 | 4550 | 860 |
| NHD-4500L | 80 | 5.5 | 4500 | 4350*1980*1600 | 4850 | 940 |
| NHD-5000L | 80 | 5.5 | 5000 | 4650*1980*1600 | 5150 | 1050 |
| NHD-5500L | 96 | 5.5 | 5500 | 4950*1980*1600 | 5450 | 1120 |
| NHD-6000L | 96 | 5.5 | 6000 | 4350*2220*1800 | 5100 | 1210 |
| NHD-6500L | 112 | 7.5 | 6500 | 4600*2220*1800 | 5350 | 1285 |
| NHD-7000L | 112 | 7.5 | 7000 | 4850*2220*1800 | 5600 | 1375 |
| NHD-8000L | 128 | 11 | 8000 | 5350*2220*1800 | 5850 | 1445 |
