Paint & Spray Booth Filters Manufacturer

Paint & Spray Booth Filters

Request a Quote

View All: http://spraybooth-system.com/4-paint-spray-booth-filters.html

In addition to spray booth, we also offer various paint booth filters such as pre-filter, pocket filter, floor filter, ceiling filters. They are all made using superior quality materials, featuring high filtration performance. The spray booth filters are available with standard specifications, and can be also customized based on customer needs.

Spray Booth Pre-Filter (G2, EU2)

Features

Made using polyester fibers with a gradual increase of fiber density
The filtration efficiency values are certified according to EN779.
Anti-humidity: 100% r.F., washable
Heat resistance: 80℃/176℉
Non-flammability, self-extinguishing according to DIN53438 F1
Particle filtering size range: ≥5μm
Supplied in roll or sheet

Spray Booth Pocket Filter

Features

Made using ultra-fine synthetic fibers
Filter media contains electrostatic fibers.
Ultrasonic welding technology for pockets provides high sealing performance and high strength.
Frame: aluminum alloy, stainless steel or steel sheet coated with zinc
Efficiency class (EN779): F5, F6, F7, F8, F9
Heat resistance: 100℃
Relative humidity: 100%
High dust-holding capacity
Good breathability
Optional filtration efficiencies for pocket filter: 35%, 45%, 65%, 85%, 95%
Long service life

Paint Booth Floor Filter (G3, EU3)

Features

Made using fiberglass with a gradual increase of fiber density
Low compressibility keeps its shape and makes fiber purified air effectively.
With a high absorbency level, the floor filter is ideally used during large-area painting.
With progressive structure, the density of the fiber layers increases towards the clean air inside. This provides higher dust holding capacity.
The filtration efficiency values are certified according to EN779.
Heat resistance: 170℃
Supplied in roll or sheet

Spray Booth Ceiling Filter (F5, EU5)

Features

Made using polyester fibers with a gradual increase of fiber density
Reinforced with wire mesh or nonwoven fabric for windward side of the filter
The filtration efficiency values are certified according to EN779.
Anti-humidity: 100% r.F.
Heat resistance: 80℃/176℉
Non-flammability, self-extinguishing according to DIN53438 F1
Particle filtering size range: ≥1μm
Supplied in roll or sheet

Spray Booth Filter Paper

Features

Stapled and glued construction for high strength and long service life
With superior spray booth filtering performance, the filter paper can collect up to 6 times the capacity of common type filters.
High paint holding capacity
Low resistance and high filtration efficiency
Can be continuously used for 500-600 hours
Conforms to DIN53438 K1
For better filtration efficiency, the fiberglass and synthetic cotton can be added on the inlet side of the filter.
The filter paper can be designed with outer frame upon request.
